| VACUUM port |
Conic connector, female |
| PATIENT port |
Ø14.0 ÷ 15.5 mm (Ø 8.0 ÷ 9.2 mm with elbow connector) |
| TANDEM port |
Ø 8.0 ÷ 9.2 mm |
| Maximum suction value |
-750 mbar (-570 mm Hg) |
| Maximum flow value |
42 LPM under recommended conditions |
| Maximum graduation interval |
50 ml |
| Patient hose sizes |
nner Ø ≥ 6 mm – L max =2.5 m |
| Vacuum hose sizes |
Inner Ø ≥ 6 mm – L max =1.8 m |
| FILTER Main Characteristics |
|
| Filtration efficiency (Typical) |
99.999995% with particle size of 0.1µ |
| Membrane |
100% expanded PTFE GORETM Medical Membrane |
| Pre-filter |
Micro fiber glass |
| Support |
Non-woven PE/PES |
